Thankful… and the reason, I haven’t been posting as much…

It’s Thanksgiving Day. The day that Americans post their thoughts on things that they’re grateful for.

Two years ago, I wrote an EV Thanksgiving post focused on all the EV choices that we get in California. Since then several other models have been introduced, with the latest one being the Tesla Model X.

Another thing I can be thankful for is the safe, little EV that my mom was drving that met its untimely demise when an SUV merged into her. It did its job and protected her through the whole process and reminds me that i have to re-emerge from the cocoon I’ve been in and help her find a new EV to replace little OB-8.

I’ve been very busy lately and have started, but not finished a few blog posts that have not seen the light of day.

  • Namely a draft of my Tesla Model S 70D experience (it’s what we drove from SoCal to the Bay Area in September for the Model X Launch party.
  • A draft of my month of driving a Tesla Model S P85, P85+, P85D, and 70D in the same month.
  • and so much more… I’ll get to it… eventually.

So, loyal readers, what have I been up to?

A few months ago, I was approached and engaged by an EV Charging Solution provider [since I started writing this on Thanksgiving Day, I didn’t get formal approval to release my client’s name, so withheld for now] to assist them to manage and file a submission to design, construct, manage, maintain, analyze, and report on the nine electric charging highway corridors that the State of California, via the California Energy Commission (CEC), has decided to fund in its 2012 agreement with the states of Oregon and Washington, along with the province of British Columbia to create the West Coast Electric Highway. It’s been a fun three months of working in a field that I’ve grown into.

As many long-time readers can attest, I really “fell into” this industry and I really enjoy transitioning from a consumer to hopefully a professional in this field. I am thankful for that client and truly hope that we “win” the bid from the CEC for GFO 15-601 (which was due yesterday at 3pm.)

Since, I didn’t get a release from my client, I won’t give out the details of the proposal, but can at least talk about the CEC grant.  I can say that the approach we took gave due consideration to light duty electric vehicle drivers traveling these routes.  It wasn’t that long ago I was driving an 80-100 mile EV with no DCFC capability. (I miss my Active E.)

The CEC identified 9 highway corridors that are in need of additional DC Fast charging (DCFC or CHAdeMO and/or SAE-Combo/CCS.)

The corridors identified by the CEC are:

  1. I-5: Oregon Border to Red Bluff
  2. I-5: South of Red Bluff to North of Sacramento
  3. SR 99: South of Sacramento to North of Fresno
  4. SR 99: Fresno to North of Wheeler Ridge
  5. US 101: San Jose to Buellton
  6. I-5: Wheeler Ridge to Santa Clarita
  7. I-5: San Clemente to Oceanside
  8. SR 99: South of Red Bluff to North of Sacramento
  9. I-5: South of Sacramento to North of Wheeler Ridge

These nine corridors had differing distances, budgets, and preferred number of chargers to install. The first seven were required to have both CHAdeMO and CCS for the equipment to be proposed and the last two were secondary and required CHAdeMO only, though preferred a combo CHAdeMO and CCS, but the budgets were also very tight.

We had several months to find site sponsors, get equipment quotes, find construction partners, obtain additional funds, start the process to participate in the WCEH, and approach other constituents.

As a rEVolutionary, I am glad to see the expansion of the ability of light duty electric vehicles (your approx 80-100 mile range EVs in the parlance of the CEC proposal) to traverse the North-South corridors of California and eventually connect with Oregon, Washington, and beyond, but as a participant in the process, I’m biased. And hope that [name retracted for now, the awesome folks who hired me to work with them and get our bid in to fruition] win this bid!

I truly am happy and thankful. Hopefully by this time next year, we’re well on our way to having this DC Fast Charge network being completed to get mom in her replacement light duty electric vehicle able to fast charge from the LA Area to wherever North or South she wants to head to… ’cause my input was to ensure that folks like her can travel these distances comfortably without getting stranded… So, fingers crossed.

Happy Thanksgiving!

The untimely end of OB-8

On Saturday, September 26th my mom was driving her little blue 2013 Nissan Leaf (OB-8) that she leased on July 2013. An SUV didn’t see her and decided to merge into her lane. The most important part of OB-8’s job was to keep her safe and it did just that.


She was unhurt from the accident, she was sad for her little blue Leaf, but in good spirits at her getting through the accident physically unscathed.

Longtime readers of the blog remember welcoming mom to the rEVolution. And like many EV drivers, once you go EV, it’s hard to go back.

On initial review, The damage did not look that bad.


The wheel and tire looked like goners, but looks like it could be repaired or replaced.


The passenger side looked relatively unscathed. However, between the damage to the car and the depreciated value of the 2013 Leaf, the insurance company declared the car a total loss.


More shots of the car from the passenger side.


The charge port door was stuck.


Close up of the charge port door.



The battery is still in good condition, or at least it still kept its charge.


Thus, with 17,893 miles in a little over 2 years, we had to say goodbye to OB-8, Mom’s Ocean Blue 2013 Leaf.

Mom leased OB-8 and the residual value on the statement was about $6,300 more than what the adjuster had valued the car for. We initially were wondering whether Nissan would allow us to apply the $5,000 price reductions that 2013 Leaf lessors were offered a few months ago as a totaled car is effectively bought out.

Luckily, Nissan had Gap Insurance on the car, so she just had to pay her deductible and was able to walk away from the car. Had she purchased the car and not purchased this insurance, she would have been liable for this shortfall on a loan.


The 2016 Leaf with 6 kWh more in the SV and SL packages seem to be a no brainier, but there are definitely more options. Though mom originally wanted to be able to DC fast charge she only did one DCFC and that was when I trained her on using the CHAdeMO.

So, what’s next? Stay tuned. We’re checking out alternates for her, too bad the Model 3 or Bolt EV isn’t out yet. However, it’s a good thing I started test driving new EV choices during National Drive Electric Week 2015, but that’s another post.

Observations from the Model X Launch Party

On the morning of September 21, 2015, I received an email from Tesla.

Model X Invite 2015-09-21

It was an invite to the Model X Launch Party.

It is a surprising invite as my wife and I do not have a reservation for the Model X. The event was going to be held at Fremont and I figured to go ahead and RSVP positively as Tesla events tend to “sell out” quickly. I figured that we could always cancel a positive RSVP if it turned out that we would not be able to make the 350+ miles from our home to the party.

We decided to go.

The trip to Fremont is approximately 350 miles and through a minimum of two superchargers for us (assuming a good charge at home to start.) However, it would turn out that this trip will be using a Loaner 70D and not our S85. I will write about the trip in a later blog post and focus this post on the actual Model X Launch Party and our impressions of the car itself.

So, the start of the party is at a Fremont location that used to be the Solyndra headquarters. This is the same building that Tesla was recently in the news for Tesla’s expansion into the space. It’s nice to see Tesla re-purposing a new asset for this party before they re-furbish the location for their expansion. We’ll start this post with our arrival at the location.




Tesla expected a lot of people to the event that they secured off-site parking and provided shuttle services. We had expected to be directed to these overflow lots, but lucked out and parked in the event parking location.


With a happy Dennis at the end of the line for the event. Tesla was pretty well organized at the early portion of the event and the line was winding in an orderly manner. However, the line was longer than the barriers and folks were asked to line up without the guiding barriers very soon after.

There was a drone taking pictures.




I was preparing to report on the event for my Twitter followers. So, I had my mobile reporting devices/phones at the ready.


However, soon after the doors opened and the second set of folks in the line got into the building, the crowd descended into chaos and those of us following the queue were at a disadvantage. What had once been one of the more orderly starts to a Tesla event, morphed into a free-for-all.

Knowing how late Elon usually is for these things, we knew that as late as we may be, Elon will be later. As we entered into the building, we were greeted by a Big X… which obviously marks the spot.


There was a cool “red carpet background” off to the left of the entrance which makes for ideal photo opportunity.


Once in the building, we were in a large room for cocktails and hors d’oeuvres



Since we drove to the event, I made sure to have my usual “virgin” Rum and Diet Coke… We parked ourselves in the back of the room, in an elevated stand so that we can have a good view. Walking around the room, I spotted a garage door in the main room.


As we were wondering if the X was going to be driving out of that garage, that notion was quashed when it turned out that Tesla had other ideas, as a new set of doors opened and the cars were being presented in ANOTHER great room.


IMG_0115 IMG_0119We tried to hang out in the reveal room




We had a rather tough view from the right side (a function of many people and being “height-challenged”) Our view of Elon was not as good as the one for the D Event.





We heard Elon discuss the car’s self-opening front doors.  The biohazard air filtration that the Model X is equipped with.

We noticed that there was video of the event from the original “holding room.” So we headed back there to get a better view.


We had a better view of the festivities, but a poor opportunity for further pictures.  (like the one with the Model X pulling the Airstream, etc.)

So, we just watched the rest of the presentation from the holding room.

One thing that we did get to do was to get in line for a ride in a production Model X.


This was through the randomized badge holders that we received when we got to the event and we got our numbers in the 600s for the ride. Which meant a long wait in the outdoor lounge area.


We got to meet people and see the cars be driven.








As we waited, kept taking pictures of folks on their drives.



Several hours later, our number was called… And we got to stand in line again.


This was another 30 or so minutes of waiting, and we were getting closer to the front.





As we got closer to midnight, we were up.  As luck would have it.  we would HAVE to be a Blue one for our ride…


And your author has to get a shot in front of the one we’re riding.


We did shoot a video inside the car, but we were running out of juice on our devices as we got to ride just after midnight.


We did get some stills of the car that we were riding in.  But since there were two of us, we got to sit in the second row seats.  The vehicle we were in was outfitted with the three row second seat configuration.





The hinge of the Falcon Wing.


The empty second row we sat in.


We headed back in to get a close up look at Elon’s Founder VIN #1.

It’s a beauty…




There is no removable nosecone on the Model X, it’s all one piece.


Headlights look different from the S IMG_0167

Full car, but folks seem ok…




A fine detail from the outside that tells you it’s a Founder’s series Model S.


In closer


Patiently waiting for my turn inside Elon’s car’s driver’s seat.


Finally in the front seat.



Fiddling around


Frunk space


A closer look at the Model X Frunk


Better view of the falcon hinge.


Step in.


The screens from the driver’s seat.







The Panoramic Windscreen


The sunvisor on the side


Sunvisor extended


Another shot of Vin 1 again.



Opening the Falcon Doors…


Here is the door opening in a video.


In front of Elon’s car.


We left the party late… But there were still folks in line for their rides.



We enjoyed the vehicle and the event.  The event was packed and the disorganization apparent, but that has been the typical of Tesla events.  It took forever to get a ride in the Model X.  As I had previously mentioned, we were surprised to have been invited to the Model X Launch and appreciate it.  I can say that after taking the time to experience the vehicle, we are now tempted to get one.  Eventually.  Perhaps in a few years when there are more CPO Model X we would pick one up.

There are more pictures at our flickr album, as usual – Model X Launch

Our third year of Solar usage.

Projected Usage 2015-09-09

This is a third year update. Click here for the 2nd Year of Net Metering.

It’s been three years since our PTO was approved, we originally estimated our savings on driving the Active E or a vehicle like the Active E. Since then, we moved from one EV to two EVs to three EVs back to two EVs. We’ve also driven around a lot and our mileage has grown significantly since then. I haven’t done the math, but estimated that we’re either at break-even this year or definitely in a few months.

In our first year of Solar use, we had a credit. Which, as we found out, we could not claim. Because, it turns out, Net Metering means that though we’re credited for the production at a $ rate, customers are paid out on OVERPRODUCTION of power and not on the CREDITS earned. What this means is the system produced greater kWh of energy than consumed by the end user. If this is the case, the customer is PAID OUT the power times the wholesale rate of production. Last year, we paid over $200 to SCE for the entire second year of Solar. This third year, coupled with our nearly a month of travel to Maine and back in our Here, There, and EVerywhere roadtrip, we’ve been out of the house for about a month. So, that created a month of overproduction. As a result, the annual net metering statement was for approximately $40 for Year 3.

This full third year of solar production is basically the Model S and Roadster. What is interesting is that our usage this past 3rd year probably would have cost us less than Year Two’s Annual bill. But the month off really helped. At less than $4 a month for power for the third year is greater than I expected. So, I chalk this third year as a monumental year. Considering our average electric bill prior to going EV and solar was closer to $200 a month, it is incredible to get most of our transportation and home energy use at so little.

Now, this current fourth year, I wonder what our bill will be. Most of the past three years our electric tariff was on TOU-D-EV. This was a special whole house rate with a discount for EV drivers. A few months ago, Southern California Edison got rid of that tariff and adjusted the Time of Use tariffs so that the times that start with Peak, Off-Peak, and Super Off-Peak.

Under TOU-D-EV, the Peak rates were from the hours of 10am-6pm M-F, the Super Off-Peak hours were from midnight-6am every day, and Off-Peak is any other time. This was great because Solar was credited during the peak times most days and helped off-set a lot of the costs.

Under TOU-D-A, the Peak rates are now from the hours of 2pm-8pm M-F, the Super Off-Peak hours are now from 10pm-8am every day, and Off-Peak is still any other time. Though the Super Off-Peak hours are longer, the effect of moving peak time to the hours between 6pm-8pm means that we’re no longer generating credits at the Peak rate between 10am-2pm. Additionally, we’re spending more between 6pm-8pm because we’re paying at Peak rates and not Off-Peak rates.

So, I’m projecting paying a little bit more for electricity next year… Unless we go on yet another LONG roadtrip.

MyEV post-mortem review…

A few months ago I published a guide to install the MyEV on our Tesla Model S. What I didn’t share in the original post, but did on subsequent comments is the purpose of the support of the Indiegogo project – MyEV Electric Vehicle Logger and App.

Since we’re a two electric vehicle family, there is some healthy competition between my wife and I on who is the “more efficient” EV driver. The marketing for the MyEV project introduced the fun, social gaming concept using the loggers that MyCarma built for the MyEV product. Since my wife drives a 1.5 Tesla Roadster, I made sure that the folks at MyCarma are able to support her car for the purchase of the two units. I was pleasantly surprised by their positive answer.

The original version of this post was to be along the same lines of the installation guide for the Model S, but we ran into some snags with the way that the Roadster reports itself. Furthermore, it appears that we were the only Roadster owner to support the project for the Roadster. In the end of the day, the Roadster reported data at a rate that was too much for the logger. I appreciate the effort from MyCarma to try to resolve this challenge. Especially since I needed them to make the product work in conjunction with OVMS.

Here is the Custom Roadster cable to the MyEV unit.

IMG_20150429_162640The folks at MyCarma were aware of my requirements to have the unit work with OVMS, so they sent me a Y-cable for the Tesla Proprietary diag port with custom OBD adaptor. IMG_20150429_162701

Like I said, this one is built for the Roadster

IMG_20150429_162728Here is the cable chained up. IMG_20150429_162807

And connected

IMG_20150429_162838Here is the footwell with the OVMS installed in the Roadster. IMG_20150429_171344

Pulled the cable and OVMS off…


When connected, the Bluetooth connection should work.

IMG_20150429_171029And start transferring the log files. IMG_20150429_170949

Here’s what the setup looks like, before it is tidily installed.

IMG_20150429_170848Then put it back in place. IMG_20150430_135749

So. It all hooked up just fine. The problem lay with the fact that though it looked like the unit was logging and transferring it actually wasn’t. I tried playing around with it and finally asked for help.

Tech Support at MyCarma replaced some cables, did some programming and generally tried to help me for at least a month if not longer. At the end, since we were the only Roadster purchasers of the product, it became cost ineffective for them to figure it out and offered me a refund for the unit. I explained to them the reason why we purchased two units (one for the Model S and the one for the Roadster) and they went ahead and refunded us for both units.

The app looks like a lot of fun, but we really needed it to work for both vehicles and it was quite good customer service of MyCarma to provide us with the resolution. I continue to hope that they fix the Roadster, but lacking any further sales. It’s like Waiting for Godot.

[Added at 10:20 PM 9/27/2015 – I forgot to add pictures of what the software looked like when I was using the product]

All these screens are for the Model S as the Roadster one never really processed the data properly. The roadster processed at a speed that the logger could not figure out.

Here is the summary of the power charged for as long as the unit was plugged into the Model S.


Here is the charging histogram of when the most amount of power was added to the car. Considering that the unit was installed before the start of our Here, There, and EVerywhere roadtrip in May 2015.


Several leaderboards, this one is for the Same Model (Model S) in the Same Region (California?)


The next leaderboard is for All Cars in the Same Region. IMG_1040

The last leaderboard is for all cars in all regions.


Model S at 47,000 Miles. What About that Extended Warranty?

We got home and parked in our parking spot in our garage at exactly 47,000 miles.


We’ve had the car since November 2013, so, this means that we’re probably going to hit 50,000 by the end of the year.

So, it got me to think about whether to get the extended warranty or not, and this thought process led to me reading the Out of Warranty Concerns thread on

Apparently, the Model S extended warranty has some interesting features to it. Aside from the $4,000 cost to purchase the warranty, there is also a co-pay of $200 for each system that is reported.

So, if there’s a problem with the charge port door, pano roof, and something else, the co-pay is $600 and not $200. Considering the cost of the warranty, and what is normally in the marketplace, it seems that the Tesla Extended Warranty is priced quite high. Perhaps, Tesla should offer multiple levels of warranty.  A higher premium with no-copay, for example. As it stands, the current program shouldn’t really be called a warranty as it doesn’t mirror the experience and expectations set up by Tesla service in the first 50,000 miles of ownership.

At 47,000 miles, it’s time to seriously consider whether to opt for the warranty or not. Perhaps it’s time to talk to my service department and ask for an approximate cost of all the items that have been done on the vehicle during the previous 47,000 miles.

On another note, between the ActiveE at 54,321 miles and the Model S at 47,000 miles, I would guess that I, personally, have driven 100,000 EV miles.  Since I share driving the cars with my wife and her Roadster is just over 17,500 miles, I think this is a good approximation.  So, “Yay me!”

[edited 8:45 AM PDT 8/6/2015 to include 2 referral paragraphs below]

You know, that referral program EVERYONE is sending links to… add mine – after all, if ONLY 4 of you have been convinced by me to go pick up a Model S during this test period, then I can at least get the warranty for free.

For those that are unfamiliar with the referral program, here is the official Tesla Link. So, you’ll save $1,000 USD (if you’re in the US) or whatever the equivalent is in your region (I clicked on a few out of US links to folks I knew and it defaulted to USD for me) if you build and buy a new Model S under that link and as a referrer, I get $1,000 in credit, which I figure to use for my warranty. However, only use my link if I helped convince you to get your Model S.

Update to CHAdeMO Instructions and Review – Efacec and Greenlots Combo CHAdeMO/CCS

My original instructional post for using CHAdeMO only covered two different CHAdeMO chargers. The Eaton and the Nissan CHAdeMO chargers. Yesterday, I found a combination CHAdeMO/CCS charger from Efacec (the Evapower EV QC 50) at the ARTIC, the Anaheim Regional Transportation Intermodal Center.


I first noticed the ARTIC from the side of the 57 freeway as I zoomed by on my way home. It is a strangely modern piece of architecture on the same exit as “the Pond” and Angel Stadium. As we passed it on that first drive and on every subsequent drive since then, my wife and I often wondered what it was. It looked like a Disneyland monorail station, except Disneyland was several miles away from the sporting venues in Anaheim.

In preparing to write this update on how to charge using the equipment at this location, I ran into several links about the site that was not very positive about this $189 Million Transit hub.  From OC Weekly when it first opened.  To an LA Times review a week later.  To an update on its operational challenges from the OC Register, half a year later.  Regardless of what the critics may say about this location.  Many of what used to be free to charge CHAdeMO L3 chargers have now been converted to paid use and it is comforting to still have options that currently do not charge for the privilege to charge at higher rates of speed.



As mentioned, this particular DC Quick Charger is a combination CHAdeMO/CCS charger. What this means is that there are two different “heads” to the Quick Charger, the CHAdeMO one which the Mitsubishi iMiEV , Nissan Leaf, and the Tesla Model S (with an adapter) uses, and a CCS (AKA the “Frankenplug”.) The CCS one is what the BMW i3, Chevy Spark, and others use.


The CHAdeMO is the one on the left and CCS is the one on the right.

In my original post, I had yet to use a CHAdeMO that has been converted to a pay system. During our trip to Vermont, we actually used a couple of Nissan CHAdeMOs that have been converted to a pay system and require an RFID and payment to charge.  However, we lucked out when the NRG eVgo CHAdeMO was still in its introductory free period.

In addition to an RFID Card, the Efacec system at ARTIC also uses the Greenlots App to initiate the charging session. However, there are a few strange things about this particular location. Though there are few Greenlots locations on the map, this particular one does not show up in it.

Since the system has two ports, there is a set of CHAdeMO and a set of CCS instructions.


We’ll be following the CHAdeMO instructions.


So, aside from downloading the App before charging at this location, I went ahead and followed most of the instructions and steps that I wrote in my original guide.

We pick up at Step 5, we still need to make sure to follow Step 4 and align the notches appropriately, it won’t fit otherwise.

Step 5 is to mate the CHAdeMO to the CHAdeMO to Model S Adapter.

So, on the Efacec L3 charger, it looks like this.


Like the Nissan CHAdeMO adapter, make sure to pull the trigger on the Efacec CHAdeMO to secure the piece to the adapter. Now, with these App initiated.

Step 6 is to plug the Adapter to the Model S. Here is the Efacec CHAdeMO pictured:


It looks similar to how the Eaton sits on the Model S.  I use the cable to push the Model S to CHAdeMO adapter up so that the weight is on the CHAdeMO cable rather than pulling on the Model S port.


Now where we differ from the original steps come in a new Step 7.  Now with this new step, all the other steps get pushed back one.

Step 7 is to authenticate with the charging network.  With this Greenlots App, I scanned the QR Code on the charger. If we had the RFID card, you just swipe it. Additionally, it seems that there is also a Credit Card reader built-in to the charger. However, since this location is free, I chose the QR code method.


Step 8 is to start the charge. With the method I chose, the Greenlots App shows a virtual button to choose which port to initiate charge with. So, I started the charge for the CHAdeMO, which is on Port 1.


Aside from starting it from the App, the charger still presents the user with a physical button to complete the charge initiation on the Efacec charger. The soft button on the upper right becomes a START button.


Step 9 Go back to the car or go about your business, but put a note on the car if you do leave so that anyone who needs to use the charger can contact you.  If you choose a note, let me recommend the EV Card from Plug In America or Jack Brown’s Take Charge and Go tags. Additionally, I would recommend checking into Plugshare so that anyone looking at the location remotely will know that someone is charging, at the moment. On the display of the charger you will notice that the battery capacity and start of charge shows up.


Green light on the Model S chargeport tells you that the car is charging.


If you go back to the car, you will notice the charge speed of CHAdeMO. As opposed to the Eaton and Nissan chargers, the Efacec at this location was providing me with 152 to 156 miles per hour. I forgot to photograph the screen on the Model S, but I did take a photograph of the charger display before it completed.


There is no estimate of how long the charging will take, but it does show the elapsed time charging, the amount of energy provided to the car and the car battery’s state of charge (SOC) percentage in real time.

The Greenlots app does a funny thing somewhere around the 30 minute mark, the app does not provide the status of the current charging session.  Before the 30 minute mark, it actually provides a snapshot of the charging session that is anywhere from most current status to as dated as a few minutes (it batch updates).  When it does provide this status, I believe that I saw it provide for a method to STOP charging from their app.  However, after the 30 minute mark, the session disappears from the app.  In order to stop the charging session, one needs to press any of the buttons on the charger directly.

Since no one was waiting, and I was just hanging out at the car, I figured to get it close to full.

Step 10 When done using the charger, press the STOP button


When I press one of the buttons and the stop is displayed, the screen goes from black to white. I figured to wait until I got to 47 minutes of charging.


Then press the Stop button (the upper left soft-key).

If you press that button the screen updates itself, first with the following “Ending Process message”.


Then the charge ended by user message.


Since I registered for an account, I actually receive an email and text message with the charging sessions statistics, cost, kWh, and time at charger.

From: “”
To: {Me, the Happy Greenlots user}
Sent: Wednesday, July 15, 2015 5:18 PM
Subject: Unplug / Charging Ends

Your vehicle has stopped charging at 43100, ARTIC. You have used 29.61 kWh for 0 hour(s) 47 minute(s).

Billing Details

Sale Amount : 0.00 USD
Tax & Fee : 0.00 USD
Transaction Charge : 0.00 USD
Total Cost : 0.00 USD

Thank you
The Greenlots Team

Step 11 Detach the Adapter from the charger’s CHAdeMO cable.

The Efacec CHAdeMO is similar to the Nissan charger in that there is a button on top to detach it from the Model S cable.

Step 12 Return the cable back to its proper location.


Step 13 Return your CHAdeMO to Model S Adapter back to your car and drive off.


If you’re interested in more pictures of the CHAdeMO to Model S Adapter, here’s my flickr stream. And if you’re looking for the instructions of the same things on a Nissan or Eaton Charger, here is the link to the original instructional post for using CHAdeMO that I wrote a few months back.


Since this is a combo CHAdeMO/CCS station, I don’t know if it is one of those sites that only lets one car use the DCFC on EITHER the CHAdeMO or CCS OR if it is one that lets two cars use both at the same time. No one else showed up while I was there the 47 or so minutes at the site. The only other EV was a Leaf that was using the L2 J1772 stations that were next to the DCFC (pictured in the background below.)


Something to see some other time. Seeing that many of the DCFC are available for at least $5 to initiate charge, I probably will only use this “in a pinch.”
